Super-Go: An Industrial IoT bot

Super-Go: An Industrial IoT bot

This IoT bot would enable you to place order anytime anywhere. Can be used in any shop or industry to avoid queues and increase efficiency.

Things used in this project

Hardware components

Arduino UNO & Genuino UNO
× 1
WIZnet WIZ750SR
× 1
HC-05 Bluetooth
× 2

Software apps and online services

Amazon Alexa Alexa Skills Kit

Story

Schematics

Architecture

This is the Working Methodology of Super-Go

Code

Super-Go

Arduino

The robotic Arm is programmed to perform the requested task.
//#include
char c=0;
//L2
int m1= 8;//forward
int m12=7;//forward
int m2=5;//end point
int m22=4;//end point
//L1
int m3=9;//circle
int m32=10;//circle
//L3
int m4=11;
int m42=12;
//for chasis
int m5= 3;//forward
int m52=2;//reverse

void L1();
void L11();
void L1_stop();
void L2_stop();
void gripper_stop();

void L2();
void L22();

void gripper();
void grip();

void L3();
void L33();
void L3_stop();

void sensor();

void robo_forward();
void robo_reverse();
void robo_stop();
char state;


void rice();
void sugar();
void dal();

void stop_all();

void setup() {
  Serial.begin (9600);



  pinMode(m1, OUTPUT);
  pinMode(m12, OUTPUT);
  pinMode(m2,OUTPUT);
  pinMode(m22,OUTPUT);
  pinMode(m3,OUTPUT);
  pinMode(m32,OUTPUT);
  pinMode(m4,OUTPUT);
  pinMode(m42,OUTPUT);
  pinMode(m5,OUTPUT);
  pinMode(m52,OUTPUT);

}

void L1_stop()
{
   digitalWrite(m3,LOW);
}


void L1()// rotation
{
digitalWrite(m3,HIGH);
  digitalWrite(m32,LOW);
}

void L11()//anticlockwise rotation
{
  digitalWrite(m3,LOW);
  digitalWrite(m32,HIGH);
}

void L2_stop()
{
  digitalWrite(m1,LOW);
  digitalWrite(m12,LOW);
}
void L2()//bending arm
{
  digitalWrite(m1,LOW);
  digitalWrite(m12,HIGH);
}

void L22()//arm up
{
  digitalWrite(m1,HIGH);
  digitalWrite(m12,LOW);
}

void gripper_stop()
{
  digitalWrite(m2,LOW);
  digitalWrite(m22,LOW);
}

void gripper()
{
  digitalWrite(m2,HIGH);
  digitalWrite(m22,LOW);
}

void grip()
{
  digitalWrite(m2,LOW);
  digitalWrite(m22,HIGH);
}

void L3_stop()
{
  digitalWrite(m4,LOW);
  digitalWrite(m42,LOW);
}
void L3()
{
  digitalWrite(m4,LOW);
  digitalWrite(m42,HIGH);
}

void L33()
{
  digitalWrite(m4,HIGH);
  digitalWrite(m42,LOW);
}

void robo_forward()
{
  digitalWrite(m5,HIGH);
   digitalWrite(m52,LOW);
}

void robo_reverse()
{
 digitalWrite(m5,LOW);
 digitalWrite(m52,HIGH);
}

void robo_stop()
{
   digitalWrite(m5,LOW);
 digitalWrite(m52,LOW);
}

void loop() {

if(Serial.available()>0)
{
  while(Serial.available()!=1)
  {
      state=Serial.read();
      Serial.print(state);
      }
}

switch(state)
{
  case 'k':rice();
           state=0;
            break;

  case 'z':sugar();
            state=0;
            break;

  case 'b': dal();
            state=0;
            break;

  default: stop_all();
          break;
}

}

void rice()
{
// if(state=='k')//rice
// {
  int i;
 Serial.print("2");
 robo_forward();
 delay(500);
 robo_stop();
 delay(50);

 gripper();
 delay(1500);
 gripper_stop();
 delay(50);


for(i=0;i8;i++)
{
  L2();
 delay(50);
 L2_stop();
 delay(35);
}
 L2_stop();
 delay(50);
 grip();
 delay(1700);

 L22();
 delay(600);
 L2_stop();
 delay(50);
 L1();
 delay(1200);
 L1_stop();
 delay(50);
 for(i=0;i8;i++)
 {
 L2();
 delay(50);
 L2_stop();
 delay(35);
 }
 L2_stop();
 delay(50);
 gripper_stop();
 delay(50);
 gripper();
 delay(1500);
 grip();
 delay(1700);
 gripper_stop();
 delay(50);
 L22();
 delay(600);
 L2_stop();
 delay(50);
 L11();
 delay(910);
 L1_stop();
 delay(50);
  robo_reverse();
 delay(490);
 robo_stop();
  state=0;
 }

void sugar()
{
//else if(state=='b')//sugar
//{
int i;
gripper();
 delay(1500);
 gripper_stop();
 delay(50);
 for(i=0;i8;i++)
{
  L2();
 delay(50);
 L2_stop();
 delay(35);
}
 L2_stop();
 delay(50);
 grip();
 delay(1700);

 L22();
 delay(600);
 L2_stop();
 delay(50);
 L1();
 delay(1200);
 L1_stop();
 delay(50);
 for(i=0;i8;i++)
 {
 L2();
 delay(50);
 L2_stop();
 delay(35);
 }
 L2_stop();
 delay(50);
 gripper_stop();
 delay(50);
 gripper();
 delay(1500);
 grip();
 delay(1700);
 gripper_stop();
 delay(50);
 L22();
 delay(600);
 L2_stop();
 delay(50);
 L11();
 delay(910);
 L1_stop();
 delay(50);
  state=0;
}

void dal()
{

//else if(state=='z')//dal
//{
int i;
 Serial.print("2");
 robo_reverse();
 delay(520);
 robo_stop();
 delay(50);

 gripper();
 delay(1500);
 gripper_stop();
 delay(50);


for(i=0;i8;i++)
{
  L2();
 delay(50);
 L2_stop();
 delay(35);
}
 L2_stop();
 delay(50);
 grip();
 delay(1700);

 L22();
 delay(600);
 L2_stop();
 delay(50);
 L1();
 delay(1200);
 L1_stop();
 delay(50);
 for(i=0;i8;i++)
 {
 L2();
 delay(50);
 L2_stop();
 delay(35);
 }
 L2_stop();
 delay(50);
 gripper_stop();
 delay(50);
 gripper();
 delay(1500);
 grip();
 delay(1700);
 gripper_stop();
 delay(50);
 L22();
 delay(600);
 L2_stop();
 delay(50);
 L11();
 delay(910);
 L1_stop();
 delay(50);
  robo_forward();
 delay(520);
 robo_stop();
  state=0;
}


void stop_all()
{

//else
//{
   L1_stop();
 L2_stop();
 L3_stop();
 gripper_stop();
  robo_stop();
}
